產品名稱： GF-WDZXEESR光伏電纜 | |
| 產品型號： GF-WDZXEESR | ||
| 產品價格： |
||
| 發布時間：2016/4/13 12:01:05 | ||
| 關 注 度：8949 | ||
1. 標準Standard
本產品按德國標準2Pfg 1169/08.2007、CEEIA B218-2012和Q/321084KKQ13-2015等標準生產。
This product is produced according to the standard 1169/08.2007 2Pfg 、CEEIA B218-2012and Q/321084KKQ13-2015. http://www.unitedco.cn
2. 用途 Applications
適用于額定電壓直流1.8kV直流組件與組件、組串之間、直流配電箱至逆變器之間的連接。電纜具有耐臭氧、耐酸堿、抗鹽霧和耐環境氣候等性能。The products are suitable for connection among components, among component assemblies and connection between power distribution box and inverter at rated voltage of DC 1.8 kV. The cable has resistance to ozone, acid and alkali resistance, salt fog resistance and adaptability to climate and other properties.
3. 型號、名稱Type and Description
型 號：GF-WDZX(N)EE(S)R
額定電壓kV：1.8
名 稱：光伏發電系統用直流傳輸電力電纜DC transmission power cable used for Photovoltaic power generation system
用途：本產品適用于額定電壓直流1.8kV及以下直流組件與組件、組串之間、直流配電箱至逆變器之間的連接。本電纜具有耐臭氧、耐酸堿、抗鹽霧和耐環境氣候。電纜設計采用了“8”字型結構，芯與芯用手即能分離，方便安裝。 The product is suitable for connection among components, among component assemblies and connection between power distribution box and inverter in photovoltaic power station at DC 1.8KV or below. This cable has the ozone resistance, acid and alkali resistance, salt fog resistance and adaptability to environmental climate. By adopting the "8" shape structure for the cable design, the cores can be separated with the hand from each other to ensure convenient installation.
4．規格Specifications http://www.unitedco.cn
導體截面(mm2)： 1.5 2.5 4 6 10 16 25 35
導 體 結 構： 30/0.25 49/0.25 56/0.30 84/0.30 84/0.4 128/0.4 196/0.4 276/0.4
導體 外徑mm： 1.4 1.9 2.5 3.2 4.4 5.4 6.7 7.9
最大導體電阻Ω/km. 20℃：13.7 8.21 5.09 3.08 / / / /
耐壓AC.V/15min： 3000 3000 3000 3000 3000 3000 3000 3000
電纜 外徑mm： 4.6～5.2 5.0～5.6 5.8～6.5 6.8～7.5 8.0～8.6 9.6～10.3 10.6～11.8 11.9～13.0
參考載流量A： 20 28 40 32 / / / /
電纜重量Kg/1000m： 54 69 93 104 / / / /
5．性能 Performance
1) 額定電壓：直流1800V；交流0.6/1kV
Rated voltage: DC 1800V, AC 0.6/1kVhttp://www.unitedco.cn
2) 適應的最低環境溫度為-40℃、最高環境溫度為125℃，在120℃的工作溫度下可使用20年。
Minimum permissible ambient temperature of conductor is-40℃and maximum temperature is125℃. It can be used for 20 years under the120℃operating environment condition.
3) 電纜的彎曲性能優良，最小彎曲半徑為電纜的6倍。
The cable enjoys excellent bending performance and the min. bending radius is 6 times of that of cable.
4) 電纜具有優異的耐酸、堿、油腐蝕能力，試驗結果電纜仍能正常工作。
This cable has excellent resistance to acid, alkaline and oil corrosion and it can still remain normal working after the test.
5) 電纜可抵御惡劣環境和機械沖擊，能耐受高溫、紫外線、風雨、臭氧的侵蝕，其壽命是橡膠電纜的8倍，聚氯乙烯電纜的32倍。
This cable can stand against harsh environment and mechanical compact and has resistance to high temperature, ultraviolet ray, weather and ozone, whose life is 8 times longer than that of rubber cable and 32 times longer than PVC cable.
6）鹵素氣體釋放量試驗：PH≥4.3,電導率≤10us/mm。
Halogen gas emission test: PH≥4.3, conductance≤10us/mm.
7）電纜燃燒無煙量試驗：透光率≥60％。
Smokeless quantity test: light transmittance≥60%.
8）電纜阻燃試驗達到德國標準2Pfg 1169/08.2007中的規定。
Cable flame-retardant test meet the requirements stipulated in 2Pfg 1169/08.2007
9）經特殊處理的電纜護套，有較高的機械強度，電纜可在屋頂結構的銳邊上布線，且能承受一定的壓力、彎折、張力、交叉拉伸載荷及強力沖擊。
Cable sheath that has been provided with special treatment enjoys higher-level mechanical strength, which enables the cable to be laid around the sharp edges of the roof structure and to bear a certain pressure, bending, tension, cross-tensile load and strong http://www.unitedco.cn
| 產品名稱 | 光伏電纜 |
| 型號 | PV1-F |
| 規格 | 1X4mm2 / 2x4mm2 |
| 額定電壓 | AC0.6/1.0KV DC1.8KV |
| 導體 | 56X0.3 鍍錫銅絲 / 2*56/0.3 |
| 絕緣材料 | 交聯聚烯烴 XLPE |
| 護套材料 | 交聯聚烯烴 XLPE |
| 成品外徑 | 6.0－6.15MM / 13x6mm |
