機場專用（照明）電纜

 (Lighting) Cable Specially Used for Airport

用途

適用于額定電壓（U。/U) 3.6/6kV機場內滑行 跑道燈、跑道進入燈和其他照明和信號指示燈等 照明系統。

Appcications

The cable is applicable to the lighting system with rated voltage of (IV U) 3.6/6kV such as taxi runway lights, runway entering lights and other indicating lights for lighting and signal inside the airport.

型號及名稱

Types and Designation

名稱

Designation

型號

Type

銅芯輻照交聯聚乙烯絕緣聚氯乙烯護套機場照明電纜

Copper-core irradiation Cross-linked Polythene Insulated PVC Sheathed Airport Lighting Cable

YJVD

銅芯輻照交聯聚乙烯絕緣耐候性聚烯烴護套機場照明電纜

Copper-core irradiation Cross-linked Polythene Insulated Anti-weathering Polyolefine Sheathed Airport Lighting Cable

規格                  Specification

型號         額定電壓kV  芯數         規格mm2

Type         Rating Volage Cores        Specification

YJVD         3.6/6        1       6、10

YJYD

YJYD

性能參數

耐壓12kV加壓5分鐘 90°C絕緣電阻常數3.67MQ • km 20°C導體直流電阻

Performance

Withstanding voltage: 12V，Adding Voltage for 5 minutes

90#C Insulated Electric Resistance Constant3.67Mn • km

20°C Conductor Direct Current Resistance6mm2 ^3.0812/km

10mm2 彡 1.83'n/km

20°C Insulated Dielectric Coefficient^3.5

Medium Loss Factor^0.02

Partial Discharge ^10pC

Features

1.The        working temperature of the conductor is 90°C, 105°C and 125°C respectively, and it has strong overload protection ability.

2.The        product can effectively prevent the interference of electromagnetic field with its excellent shielding properties.

3.The        product is provided with high insulation resistance and strong corona resistance ability.

4.The        integrated insulated ability of the product is highly enhanced through introducing advanced triple extrusion technique.

5.The        product is oil resisting and refractory.

6.The        product has excellent environmental stress resisting a bility, and the cable has a long service life.

6mm2^3.08 Q/km 1 Omm2^ 1.83 0 /km ^3.5 彡 0.02 彡 lOpC

20°C絕緣介電系數 U。介質損耗 局部放電

產品特點

1、導體工作溫度分別為9(TC、105°C、125'C,過 載保護能力強。

2、產品屏蔽性好，可有效防止電磁場的干擾。

3、絕緣電阻高，耐電暈能力強。

4、采用先進的三層共擠技術，提高電纜的絕緣 綜合性能。

5、耐油、耐溶性。

6、耐環境應力性能較優，電纜使用壽命長。

Conductor Conductor shield Insulation Insulation shield Steel shield
