產品用途：
本產品適用于交流額定電壓450/750V及以下的電器裝置，小型電動工具、儀器儀表、動力照明及自動化裝置等。電線的長度允許工作溫度應70~105℃。產品采用丁晴-聚氯乙烯復合物料擠包，在低溫條件下能保持良好的柔軟性，外形美觀新穎，使用方便。導體為鍍錫銅絲,易焊接。產品標準:JB6213.2-92|
標稱截面 mm2 |
規格 | 絕緣厚度 |
導體直流電阻20℃時 不小于Ω/km |
電纜最大外徑mm |
| 0.2 | 12/0.15 | 0.5 | 90.4 | 1.7 |
| 0.3 | 16/0.15 | 0.5 | 60 | 1.9 |
| 0.4 | 23/0.15 | 0.5 | 58 | 2.1 |
| 0.5 | 28/0.15 | 0.5 | 41.3 | 2.15 |
| 0.75 | 42/0.15 | 0.6 | 26.8 | 2.3 |
| 1.0 | 32/0.2 | 0.6 | 20.5 | 2.5 |
| 1.5 | 48/0.2 | 0.7 | 13.3 | 2.9 |
| 2.5 | 19/0.41 | 0.7 | 8.0 | 3.9 |
| 4 | 19/0.52 | 1.0 | 5.0 | 4.8 |
| 6 | 19/0.64 | 1.0 | 3.3 | 5.6 |
| 10 | 49/0.52 | 1.2 | 1.83 | 7.1 |
| 16 | 49/0.64 | 1.2 | 1.15 | 9.0 |
| 25 | 98/0.58 | 1.2 | 0.727 | 10.4 |
| 35 | 133/0.58 | 1.2 | 0.524 | 11.6 |
| 50 | 133/0.68 | 1.2 | 0.3 | 13.5 |
